A large DIY LEGO minifigure display case should let you reach the collection without disturbing every row. Splitting the display into serviceable bays can change the structure and the way you rearrange it. The design task is different from fitting a few extra figures into a small cover.
The concept here uses separate row carriers and accessible bays. It is an original planning layout, not a tested capacity or a construction drawing. Follow the small minifigure case guide for the individual figure measurements.
Group the collection by access needs
Decide which characters you rearrange often and which are rarely moved. Give frequently handled figures an accessible bay rather than placing them behind several fixed rows. Reserve positions for large headgear, capes and accessories.
Do not start with a headline capacity. A count is useful only after the actual footprints, row heights and opening routes have been checked. Two collections with the same number of figures may need different layouts.
Make a bay schedule
For each bay, record its row carriers, largest complete figure, clear opening and the space needed to remove a carrier. Choose the bay boundaries so one section can be serviced without removing the others.
| Record for each bay | Why it matters |
|---|---|
| Largest accessory envelope | Checks edge and top positions. |
| Carrier removal route | Checks the opening and hand access. |
| Panel support edges | Defines the clear spans. |
| Future rearrangement | Avoids trapping a favourite row behind fixed parts. |
Separate row support from the clear cover
Draw how the carriers are supported and located. Then draw the enclosure around them. If a divider supports a shelf or panel, its connection needs a structural role on the drawing. A visual line between character groups is not automatically a supporting member.
Keep the cover’s job clear. A removable front protects the view and access opening; it should not unexpectedly become the part retaining every row. Confirm how the display remains supported when one access panel is removed.
Choose serviceable panel sizes
One very wide clear front gives an uninterrupted view but creates a larger part to handle. Several independently removable fronts add boundaries, but can keep maintenance local to a bay. Compare both options at the planned viewing distance.
Make paper outlines of the panels and move them through the intended access route. Check where a removed part can be placed. A panel that can be taken off technically may still be inconvenient to handle in a crowded room.
Review support and installation as a separate task
Record the complete loaded display and the spans between supports. ACRYLITE’s different calculation tools demonstrate that the support condition matters. Do not select a sheet thickness from the figure count alone.
If the display will hang on a wall, that becomes a wall-case design project. Have the load path, back structure and fixings reviewed; a wide tabletop concept is not approved for wall use. Read the wall-mounted case design guide before committing to that location.
Leave a usable record for the next expansion
Keep the bay schedule, carrier dimensions and connector details. Plan an extension as another supported bay rather than an extra load attached to an unreviewed edge. Recheck the structure whenever the arrangement changes.
For a ready-made option, compare minifigure display cases by actual layout and access. A quoted capacity should be checked against your own figures and accessories.
Sources and editorial method
Sources reviewed 15 October 2026. This article uses published documentation and original explanatory diagrams. It does not report a hands-on product test.
